Rough terrain crane RT-30 for hire in Westmead, NSW 2145

Description

Lifting capacity

32 T @ 3 m radius on fully extended outriggers.

Engine

Suitable water cooled diesel engine of adequate horse power.

Transmission

Power shift with built in hydraulic torque convertor with adequate forward and reverse speeds.

Steering system

Fully Hydraulic, 4 steering modes – 2 wheel (front), 2 wheel (rear), 4 wheel & crab.

Tyres

13.00 x 25.00 offset disc, earthmover type.

Boom

3 Section, Hydraulically telescopic rectangular box type boom.

Hoist Mechanism

Hydraulic motor driven planetary gear box type.8/9 falls with 16 mm rope diameter.

Operation Weight

28,300 Kgs.

Safety devices

Pressure relief valve in main hydraulic circuit
Derricking through single cylinder with Integral pilot operated safety brake valves for controlled lowering.
Electronic safe load indicator
Over hoist limit switch with hydraulic cutoff in the event of over hoisting of snatch block.
Counter balance valve to provide controlled derricking and hoisting operation under load.
Free-wheeling safety device for automatic alignment of boom over the load 360 deg. Continuous slew.
Safety valves in all hydraulic cylinders for protection against pipe and hose ruptures.

Call now to organise a booking 1300 15.....

Attachment

Title	Rough terrain crane RT-30
Crane Size	32tonne
Mine Spec	No
Type	Rough Terrain
GPS	No
Hire Type	Dry
Ref #	DZ17092

	Bagged Hoses
	Battery and Terminals in Good working Condition
	Brake Test Certificate
	Cab in Good/Clean Working Condition
	Cargo Barrier
	Enclosed Cab
	Fire Extinguishers
	Hand Held Fire Extinguishers
	No Major Oil Leaks
	No Visible Fluid/Oil Leaks
	Rear Tyre Good Condition (Good Working Order)
	Reflective Yellow Tape
	Seat in Good/Clean working condition
	Spare Tyre and Tools
	Wheel Chocks
	Wipers and Washers
