DD2412 Double Deck Screen for hire in HALLAM, VIC 3803

Description

DD2412 Double Deck Screen available for dry or wet hire.

Its standard features include an adjustable angle screenbox support frame, 2 bearing eccentric drive shaft, under screen rubber lined sump with rubber lined trough, reject and middle grade chutes, boiling box on feed inlet and a wet sump outlet. Depending on the material and arrangement, the DD2412 can screen up to 200tph with a feed size of up to 100mm and can produce accurately sized end products. The top deck consists of mesh and the bottom deck of piano wire; however, they can be alternated and fitted with meshes, piano wire, slotted, poly panel or Rapid Screen heavy-duty scalping and finger-screening solutions to suit contractors' needs and requirements.

Features

Double deck screen box
2-deck, 2-bearing, reversible screenbox utilising mesh, RapidScreen or piano wire
Heavy-duty skid frame
5kW electric motor drives, pulleys and V-belts
Adjustable angle screenbox support frame complete with 8 spring supports
Two bearing eccentric drive shaft
Under screen rubber lined sump with rubber lined trough
Reject and middle grade chutes
Boiling box on feed inlet
Top and bottom deck spray bars
Dry screen option: Single dry sandbox
Wet screen option: Washing equipment consisting of boiling box, spray bars and wet fines sandbox
Wet sump outlet
Access walkways for maintenance

Please call for rates and availability.
