Vermer VX100 Truck-mounted Vacuum ExcavatorsRICHLANDS, QLD 4077

Description

Vermer VX100 Truck-mounted Vacuum Excavators for sale.

The Vermeer V800 and V1200 family of skid-mounted vacuum excavation units offer a multitude of unique features that enable vac truck use by both teams and individuals across a wide variety of medium-volume excavation and spoil removal applications.

OVERVIEW
The Vermeer VX100 range of skid-mounted vacuum excavation units offer a multitude of unique features that enable vac truck use by both teams and individuals across a wide variety of medium-volume excavation and spoil removal applications.

HORSEPOWER
99 hp (74 kW)

KEY FEATURES
Compact one-piece skid design. The high quality one-piece skid can be easily mounted to a wide range of truck chassis - permanently, or via container-locks for greater versatility.
Dual tank shut-off system. Reduces the risk of material entering the blower - in turn, adding greater longevity to your system.
Quieter operation. Integrated silencing system for quieter operation on noise-sensitive job sites.
Dual oil bath Roots blower. Quality blower with dual oil bath lubrication for maximum longevity. Optional Reverse Flow improves productivity with the ability to offload spoil faster and clear blockages quickly.
Optional hydraulic boom. Exclusive optional telescoping boom maintains hose length during extension and incorporates a remote controlled hydraulic valve for vacuum shut off. Available with manual or hydraulic rotation.
In-tank washdown system. Saves you cleanup time and makes it easier to remove difficult debris as it delivers a high-pressure water spray to the tank interior while simultaneously dumping material.
Cam-over hydraulic rear door. Cam-Over auto-locking design provides a positive door seal, even under reverse pressure without additional clamping requirements.
Three-stage cyclonic filtration. Superior filtration over a baghouse arrangement, and located at chest height for easy removal for cleaning if required.

MACHINE SPECIFICATIONS
VSK100XT-800 - VSK100XT-1200 - VSK100XT-2200
Empty Weight: 3220 kg - 3991 kg - 4472 kg
Skid Dimensions (L,H,W): 4496, 1768, 2481 mm - 5054, 1930, 2436 mm - 6883, 2743, 2413 mm
Water Tank Capacity: 410 gal (1552 L) - 410 gal (1552 L) - 935 gal (3540 L)
Number of Tanks: 2-205 gal (776 L) - 2-205 gal (776 L) - 1-935 gal (3540 L)
Spoil Tank Capacity*: 800 gal (3028.3 L) - 1200 gal (4542.5 L) - 2200 gal (8327.9 L)
*Also available in 500 gal (1892.7 L)1600 gal (6056.7 L), 2000 gal (7570.8 L), 2600 gal (9842.1 L), and 3000 gal (11356.2 L) spoil tank configuration

Common features of the VSK100XT range
Power pack: 99 hp (74 kW) Kubota Diesel - Vacuum - 1200 cfm
Fuel Tank Capacity: 83.3 L - Vacuum - 15 inHg
Water Pump: 5.6 gpm @ 3000 psi (21.2 L/min @ 206.8 bar) - Type of Filters - 2 Micron, Washable
High Pressure Hose Length: 50' (15.2 m) - 3-Stage cyclonic filtration system - Standard
Low Water Shut-off: Electric - Spoil Tank Shut-off - Dual-Electric and Manual
Tank Lift Type: Dual Cylinder - Hose Length - 3 x 3 m lengths (9 m total)
Door: Hydraulic cam-over - Hose Width - 4" (10.2 cm)

Available Options
5000 psi Water Pump: 5.6 gpm @ 5000 psi (21.2 L/min @ 344.7 bar)
Deep Vacuum blower: 99 hp (74 kW) Kubota Diesel, 1200 cfm, 23 inHg
Reverse Flow : YES - Sewer Jetter - YES
Hydraulic Boom 4" - YES - Hydraulic Boom 5" - YES

Please call for more information or to arrange an inspection.
